Get the right crystals.
In every batch
A poor crystal size distribution leads to product quality issues and a high recirculation rate, wasting energy, time and water. It decreases the yield of crystallization, leaving excess sugar in the molasses. The issues caused by the presence of fines and conglomerates can be really painful.
Fear not, as we're here to transform this situation. Our solutions are designed to eliminate these hurdles and revolutionize your crystallization process.
Control Your Crystals
with SeedMaster
SeedMaster-4 is a unique crystallization transmitter which allows for accurate in-line and real-time monitoring and control of supersaturation over the complete process of crystallization.
Supersaturation
The most important parameter of crystallization is supersaturation. That is the driving force of crystal growth. If supersaturation is too low, crystals will not grow. If it is too high, spontaneous nucleation will happen, ruining product quality.
To achieve the highest possible product quality, supersaturation must be kept in an optimal range. To control it, we need to know its value: accurately, in real time, throughout the whole batch. We designed the SeedMaster instruments for this purpose.
SeedMaster-4
SeedMaster instruments provide real-time, online data on supersaturation and other key crystallization parameters. The provided data can be used to implement the supersaturation-based control of the crystallization process. Optionally, SeedMaster itself can include the control implementation.
Using this type of control, it is possible to radically improve the crystallization process, resulting in better crystal size distribution, efficiency, and yield.
Features
Get the right crystals
SeedMaster instruments can help achieving superior crystal quality. Get rid of fines and conglomerates!
Increase yield
By improving crystal size distribution, our instruments can reduce recirculation and increase the yield of the process significantly.
A more efficient process
In many cases, using the SeedMaster can reduce the usage of steam, water, and energy.
For any crystallizer
Can be used for both vacuum pans and cooling crystallizers.
Multiple crystallization parameters
SeedMaster-4 provides a real-time signal on, supersaturation. crystal content, crystal size, mother liquor purity.
Dual system
One SeedMaster-4 can serve up to 2 crystallizers simultaneously.
